Timloc 6M Roll Out Dry Fix Ridge Kit

Convenient 1-pack mechanical fix solution for roof ridge installations. Designed for use with most types of slate, concrete or clay roof ridge tiles. Suitable for use on new build and existing roof applications.

Faster, cleaner, and generally safer alternative to traditional mortar installation methods.

Helps to meet BS5534 code of practice for slating and tiling and BS5250 code of practice for control of condensation in buildings.

Use:

• Most types of slate, concrete or clay roof tiles
• Round or angled ridge tiles
• Most pitched roof types from 15-55°
• New build and retro-fit projects

Features and Benefits

• Preassembled fixing screws and clamping plates
• Ridge union with adjustable clip positions for ridge tile thickness
• Universal ridge batten strap for ease and flexibility
• Long lasting, reliable, and virtually maintenance free
• Protects against wind uplift, water ingress and general deterioration
• Provides 5000mm²/m (5mm continuous) ridge ventilation
• Easy, fast, clean and generally safer mortar free installation
• Can be installed in virtually all wet and cold weather conditions
• Water resistant yet air permeable membrane roll
• Strong, malleable and corrosion resistant aluminium flashing secured to roll
• 55mm wide ridge union width provides additional water bar protection
• Assurance of stainless steel clamping plates
• Maintains consistently smart appearance
• Not impacted by building settlement
• Helps prevent entry of large insects, birds, and vermin into the roofline

Quality

• Helping to meet:
  • BS 5534 Code of practice for slating and tiling
  • BS 5250 Code of practice for control of condensation in buildings
• Complies with all other relevant regulations and standards
• Independently tested and complies with BS 8612

Material and Colour

• Ridge unions and clips manufactured from UV protected and colour fast polypropylene. Water resistant and ventilated roll membrane with attached self-adhesive and coloured aluminium flashing. Galvanised steel ridge batten straps. Stainless steel screws and clamping plates.
• Available in black only.

Components supplied in the pack

• 1 x 6m vent roll membrane with self-adhesive flashing
• 13 x fixing screws and clamping plates
• 13 x ridge unions
• 26 x ridge union clips
• 10 x ridge batten straps

Ordering Information

• Select the relevant 6m roll out dry fix ridge kit colour for the project. Order 1 pack for roof ridge lengths up to 6m. Sequential packs can be installed.
• Please allow for a minimum roll membrane overlap of at least 150mm.
