The CLARITY M provides a comprehensive set of precision tools essential to the success of any audio producer. Ideally suited to stereo and 5.1 mixings, mastering and post-production, CLARITY M’s 7" high-resolution LCD display provides a wealth of monitoring information at-a-glance via a single screen. Metering options include; the legendary LM6 Loudness Radar Meter; a state-of-the-art true peak meter; downmix compliance; stereo/surround correlation meters; and an RTA (Real Time Analyzer).
Source inputs come in a vast array of options including USB for hassle-free VST, Audio Units and AAX plug-in metering; 6 channels of unbalanced AES3 digital audio on 75 Ohm BNC connectors for broadcast-grade 5.1 metering; and stereo optical for maximum flexibility. CLARITY M is fully compliant with all major broadcast standards including ITU BS.1770-4, ATSC A/85, EBU R128, TR-B32 and OP-59, and is recommended for all studios environments.
Features:
- Professional stereo and 5.1 audio meter for mixing, mastering and post production
- 7" high-resolution LCD display for precision metering in all studio environments
- USB connection for hassle-free VST*, Audio Units and AAX* plug-in metering
- Compliant with all major broadcast standards including ITU BS.1770-4, ATSC A/85, EBU R128, TR-B32 and OP-59
- 6 input channels of unbalanced AES3 digital audio on 75 Ohm BNC connectors for broadcast-grade 5.1 metering
- Legendary LM6 Loudness Radar Meter provides all essential loudness monitoring information on a single screen
- State-of-the-art true peak meter identifies clipping in DACs, CODECs and downstream filters
- Downmix compliance meter based on TC Electronic's industry-standard loudness measurement algorithms
- Precision stereo/surround correlation meters
- High accuracy real-time analyzer with 1/3 octave resolution
- Detailed statistics overview for all key loudness measuring parameters
- Provision for custom logo on an LCD display
- RAM-mount compatible for wall or ceiling mounting (not included)
- Stereo Optical Input for TOSLink source
- General purpose input (GPI) for meter reset
