LIVE Electrical RA116B-030 Type A Single Module 16A B Curve 10kA 30mA High Immunity RCBO

Product Description

Type A RCBO Single Module

LIVE Electrical brand high immunity RCBO is an ideal solution for providing over current & earth leakage protection. They ensure reliable protection to people & installation in networks having pulsated DC, harmonics & transients currents, while maintaining continuity of supply by reducing nuisance tripping. Handle can be locked with pad-lock to prevent unwanted operation for safety.

Specification:

• Rated current (In): 16A.
• Rated voltage (Ue): 230V AC.
• Breaking capacity (Icn): 10kA.
• Rated residual current: 30mA.
• Tripping characteristic: B.
• Electrical endurance: 400 cycles.
• Mechanical endurance: 100000 cycles.
• Complies with BS EN 61009-1.
• Type: A.

Data Sheet:

LIVE Electrical Catalogue:
