The Teledyne FLIR T1010-28-NIST HD Thermal Imaging Camera is engineered for professionals who demand high performance and exceptional thermal accuracy. With a 1024 x 768 resolution and 28° lens, this camera delivers high-definition imagery ideal for detecting even the subtlest of temperature differences in electrical, mechanical, and building inspections.
Featuring Teledyne FLIR’s MSX and UltraMax technologies, the T1010-28-NIST enhances image clarity and resolution beyond standard capabilities. The MSX technology overlays visual image details onto the thermal image, making text and objects easily readable. Meanwhile, UltraMax captures and processes multiple frames to increase resolution and clarity, significantly improving measurement precision.
The integrated OSX Precision HDIR lens system ensures sharp image fidelity from wide angles to telephoto views. Its rotating optical block and intuitive user interface enable efficient operation from virtually any angle, reducing operator fatigue and streamlining inspections.
What's Included:
- Teledyne FLIR T1010 Thermal Camera with 28° Lens
- FLIR Tools Software License
- NIST Certificate of Calibration
Features
HD Thermal Resolution
Offers 1024 x 768 thermal resolution for extremely detailed thermal images and accurate temperature readings.
UltraMax Image Enhancement
Enhances resolution up to 3.14 MP by combining multiple frames, increasing detail and reducing noise for better analysis.
MSX Image Fusion
Adds visible spectrum edge details to thermal images, improving context and readability of text and features.
OSX Precision HDIR Lenses
Provides high-fidelity imaging and extended measurement range to pinpoint minute temperature anomalies from a distance.
Wide Temperature Range
Capable of measuring from -40 °C to 650 °C across multiple ranges with ±2 °C or ±2% accuracy.
Smart User Interface
Touchscreen navigation with rapid-response GUI allows fast setup and image adjustment with 1-Touch Level/Span.
Teledyne Vision Processing
Combines MSX, UltraMax, and adaptive filtering algorithms for low-noise images with exceptional clarity.
FLIR Tools Software
Enables in-depth analysis and seamless reporting of thermal inspection results.
Rugged, Ergonomic Design
Designed for durability and ease of use with a rotating optical block for flexible viewing angles.
What's Included
Included with Your Purchase:
- Teledyne FLIR T1010 Thermal Camera with 28° Lens
- FLIR Tools Software License
- NIST Certificate of Calibration
Specifications
- IR Resolution: 1024 x 768 (786,432 pixels)
- UltraMax Resolution: 3.14 MP
- Thermal Sensitivity (NETD): < 25 mK @ 30°C
- Field of View: 28° x 21° (36 mm lens)
- Object Temperature Ranges: -40 °C to 150 °C; 0 °C to 650 °C
- Accuracy: ±2 °C or ±2% of reading at 25 °C
- Spotmeter: 1
- Area Measurement: 1 box with max/min/avg
- Imaging Frequency: 30 Hz
FAQ
Q: What is UltraMax and how does it improve image quality?
A: UltraMax is a super-resolution technology that captures and combines multiple frames to enhance image detail, quadrupling the pixel count and improving measurement accuracy.
Q: What is the benefit of MSX technology?
A: MSX overlays visible light details onto the thermal image, making features like labels and edges clearer for better orientation and analysis.
Q: Can the T1010-28-NIST detect small temperature differences?
A: Yes, its thermal sensitivity of less than 25 mK allows it to detect subtle temperature differences that could indicate underlying problems.
Q: What kind of software is included?
A: The camera comes with FLIR Tools software for advanced thermal analysis and easy reporting.
