• Model: NXZ-125/4B
• Rated Current: 125A
• Poles: 4 Poles
• Rated Voltage: 400V AC
• Frequency: 50/60Hz
• Transfer Type: Automatic
• Switching Time: ≤3 seconds
• Control Mode: Automatic & Manual
• Contact Type: Silver alloy contact
• Protection Features:
  • Overload protection
  • Short circuit protection
  • Under-voltage and over-voltage protection
• Mechanical Life: 10,000 operations
• Operating Temperature Range: -25°C to 70°C
• Enclosure Material: High-quality, flame-retardant plastic
• Mounting: Surface or DIN rail mountable

The Chint 125A Automatic Transfer Switch (NXZ-125/4B) is designed to automatically transfer the load between the main power source and backup generators, ensuring uninterrupted power supply. With its robust construction and reliable switching mechanism, this device is ideal for residential, commercial, and industrial applications where continuous power is essential. The switch operates seamlessly during power outages, preventing any disruptions in critical operations.
