Specifications
Please note - specifications subject to change without prior notice.
| FRAME | Hydro formed 24" 6061 Aluminium, 11/8" Headtube 135mm OLD QR Dropouts, disc brake mounts |
| FORK | Zoom Steel Suspension fork, 50mm travel, Coil |
| REAR SHOCK | NIL |
| WHEELSET | SURFACE Custom Wheelset |
| RIMS | F: 24" Alloy Single Wall, 28H, Black; R: 24" Alloy Single Wall, 28H, Black |
| HUBS | F: Joytech, 100x9 QR, 6 Bolt, 32H Front Hub; R: Joytech, 135x9 QR, 7-Speed, 6 Bolt, 28H Rear Hub |
| TYRES | F: 24 x 2.35" Wanda P1226; R: 24 x 2.35" Wanda P1226 |
| CRANKSET | SURFACE Alloy Crank, 140mm, 32T chainring, Black |
| REAR DERAILLEUR | Shimano RD-TY500 Rear Derailleur, 6/7-speed |
| FRONT DERAILLEUR | NIL |
| SHIFTER | L: NIL, R: Shimano SL-RV400-7R Revo Shifter. 7-Speed |
| CASSETTE | Shimano CS-HG200-7 Cassette, 7-speed, 12-28T |
| HANDLEBAR | 580mm x 25.4, 10°, H:15mm, Matt Black |
| STEM | 25.4mm E:60mm H:41mm 15° , Alloy Black |
| BRAKES | F: Tektro MD-M280 Mechanical Disc Brake, R: Tektro MD-M280 Mechanical Disc Brake |
| ROTORS | F: Tektro 160mm, 6-Bolt Rotor; R: Tektro 160mm, 6-Bolt Rotor |
| SEAT POST | 27.2mm x 250mm, Alloy Black |
| SADDLE | SURFACE Kids Saddle |
| GRIP | TPR Grips, Custom Colour, 125mm |
